In the following, the charge-pumping threshold voltage and the
charge-pumping flat-band potential
are compared with the device
threshold and flat-band voltages.
From the one-dimensional Poisson equation one derives for -channel devices
with .
is the device flat-band potential. The critical
concentration
depends on the top-level duration
according
to 3.64. The device threshold voltage
follows
from 3.102 assuming
. The charge-pumping
flat-band potential can be derived in an analogous way
The critical hole concentration is given by 3.65.
The calculated
versus top level duration and
versus bottom level duration are shown in Figure 3.8.
The bulk doping
is a parameter. The charge-pumping threshold and
flat-band voltage differ significantly from the device voltages for the very
short and long duration of the top and bottom levels, while they are close to
the device voltages for medium time intervals.
The dependence of and
on the frequency of the gate
signal
may be exploited to measure the capture cross-sections
separately for electrons and holes. The derivation
follows from 3.102. It depends on the ratio
and the bulk doping
. The concentration
results as the
solution of a simple transcendental equation. By measuring the characteristic
one is able to obtain
and consequently,
. In an analogous way, the derivation of the
characteristics
can be used to extract the critical hole
concentration
and finally, the capture cross-section
. Note that both cross-sections can be measured in the
same device by the same experiment. The bulk doping profile, assumed here as
uniform with concentration
, must be measured separately. This technique
is proposed for long-channel devices. Further experimental and theoretical
work is necessary to evaluate the feasibility of this technique to be applied
in practice, in particular to examine its sensitivity and the influence of
errors in the determination of
.
