There is a wide range of areas in which high-voltage and power semiconductor devices can be applied.
Driving loads directly from CMOS based logic circuits is used among
others in automotive, mobile communication, and personal entertainment systems.
To reduce costs, the combined integration of high-voltage and power devices
together with CMOS low-power circuits on the same chip has recently become
state-of-the-art. These devices are known as smart power devices and allow a reduction in the number of components that need to be assembled on circuit boards. Beside the cost reduction, the minimization of the number of components decreases potential errors.
Ensuring the reliable operation of power and high-voltage devices requires the
consideration of impact ionization, temperature distributions, electric field
distributions, surface influences, and interface degradations. Static and
dynamic investigations must be performed likewise. The integration of low-
and high-voltage devices on a single chip as is the case in smart power devices
leads to additional parasitic effects which might cause break-down, latch-up,
and snap-back behavior. The investigation of high-voltage devices by means of
device simulation requires, in addition to profound physical models, a stable
numerical system. In particular, the simulation of impact ionization often leads to
poor convergence behavior due to its strong exponential dependence. Models used
to estimate impact ionization in drift-diffusion based models depend not only
on scalar values, but also on vector quantities. There are different approaches
to how the vectors can be approximated. The influence of various vector
discretization methods on the results of the simulations and on the convergence
behavior have been investigated. Another numerical challenge arises from the
fact that snap-back simulations need to trace non-bijective I/V curves, which
makes curve-tracing algorithms necessary. Our work focuses on the simulation of
reliability issues caused by impact ionization.
|
